Key Features of This Outdoor Double-sided 3D Holographic Fan
Double-Sided Display for Maximum Exposure
P1.0mm Pixel Pitch – Ultra High Resolution with Seamless Splicing
The core of our LED advertising fan is its ability to create a true floating 3D effect without any special glasses.
Thanks to its 4K+ resolution and P1.0 mm micro-pitch, the visuals are incredibly sharp and realistic.
Unlike standard fans, this dual-sided hologram fan projects visuals in two directions simultaneously.
This ensures your 3D advertising content captures attention from both incoming and outgoing traffic, effectively doubling your audience reach.
IP65 Waterproof Round Enclosure
Engineered for durability, the unit is sealed within a robust, high-transparency round protective cover.
This waterproof hologram fan design protects against rain, dust, and wind, making it the perfect solution for challenging outdoor environments
or high-traffic indoor areas.
Ultra-Bright LED Fan for Superior Day & Night Visibility
With a brightness of over 2500 nits on both sides, this outdoor LED fan ensures your visuals remain crisp, vibrant, and clearly visible
even under direct sunlight, overcoming the limitations of traditional screens.
Integrated & Aesthetic Design
The sleek, circular design of the protective enclosure not only offers safety but also adds a modern aesthetic. It is designed for easy hanging
installation, making it ideal for lamp posts, corridors, and window displays.
Where to Use Your Dual-Sided Hologram Fan?
Street & Lamp Post Advertising
Transform ordinary streetlights into dynamic digital assets. The hanging 3D display design is perfect for municipal projects and street-side branding campaigns.
Retail Storefronts & Shopping Malls
Hang this 56cm holographic display in store windows or central atriums. The double-sided visual ensures shoppers inside and outside the store are engaged simultaneously.
Theme Parks & Outdoor Events
Create magical experiences in open-air venues. The weatherproof 3D fan allows for continuous operation in parks, zoos, and festival grounds, regardless of the weather.
Technical Specifications of the 56cm(22-inch) 3D Fan
- Display Diameter: 56cm / 22 inches
- Material: Aerospace-Grade Aluminum Frame & Ultra Transparency Acrylic
- Display Type: Dual-Sided (Double Screen)
- Enclosure Type: High-Transparency Round Acrylic Cover
- Resolution: 3840 x 1104 pixels (High Definition)
- Brightness: 2500+ Nits (Outdoor Readable)
- Waterproof Rating: IP65
- Control Method: Cloud / App / PC / Remote Control
- Installation: Hanging / Wall Mount / Pole Mount
Products Technical Specificatioins of Holographic Display
Product size: 56 x 56 x 8 cm Use Case Studies
Display size: 56 x 56 cm 22-inch G.W.: 1.5kgs
Resolution: 3840 x 1140 pixels (Ultra High Definition)
LED Lamp Beads Quantity: 1140 pieces (4 blades x 285 pieces)
LED Lamp Beads Pixel pitch: P1.0 mm (2 pixel 1.0 mm apart)
LED Lamp Beads Type:1608 RGB (Ultra HD) Beads Size: 1.6×0.8 mm
Material: PC + Aluminum Alloy
Brightness: 2500 Nits adjustable Refresh rate: 40 Frames per second
Rated Power:96W Viewing angle: 176°
Rotating Speed: 720-900 r/min Voltage: AC100~240V 50/60Hz
Product input voltage: 24V 4A TF Card Memory: 8G
Content Format: MP4,AVI, Rmvb, GIF JPG, MPEG, PNG
Solution: Single Fan, Synchronization Multi-units Fan, Cloud remote control.
Holographic Fans: 9cm to 200cm | Scalable to 30*30m²
Custom Solutions for Your Holographic Advertising
OEM/ODM & Custom Branding
We offer full customization for this round hologram fan. We can print your logo on the enclosure frame or customize the housing color to match your brand identity.
3D Content Creation Services
Maximize the potential of your dual-sided 3D display with professional content. Our team can create bespoke 3D videos optimized for the circular, double-sided format.
Why Choose a Double-Sided Fan Over a Single-Sided One?
360-Degree Visibility Potential
While a single-sided fan only engages one direction, our dual-sided LED fan covers both approaches. When installed in a series or rotating mount, it can provide a near 360-degree visual experience.
Superior ROI for Outdoor Advertising
For the same installation cost (labor, power), a double-sided holographic display delivers twice the impressions, significantly improving your return on investment for outdoor advertising campaigns.
vs. Wiikk
P1.0 mm micro-pitch technology (vs. Wiikk’s P1.8+) = sharper, seamless 3D visuals
2600+nits brightness (vs. ~1800nits) = visible even in direct sunlight
No visible black bars or seams (unlike Wiikk’s grid lines)
10x faster setup, tool-free assembly in 1 mins (vs. Wiikk’s 10 minutes)
Outdoor environments that Wiikk can’t serve.
Lightweight & Portable: Easy to install and perfect for any setup
vs. Hypervsn
Just 1/20th the price (vs. Hypervsn’s 10%) – making large-scale deployments or SMB campaigns viable
P1.0mm micro-pitch (vs. Hypervsn’s P1.3+) – Near-identical visual impact to Hypervsn – bright, fluid, and attention-grabbing
2600+nits brightness (vs. Hypervsn’s~2500nits) = visible even in direct sunlight
15x faster setup, tool-free assembly in 1 mins (vs. Hypervsn’s 15 minutes)
Outdoor environments that Hypervsn can’t serve.
Frequently Asked Questions (FAQs)
1.Is this 56cm hologram fan truly waterproof?
Yes, this unit is rated IP66. The protective enclosure is fully sealed, allowing the outdoor hologram fan to operate safely in rain and dusty environments.
2.How do I install this hanging 3D display?
The unit comes with a specialized bracket designed for hanging from ceilings or mounting onto poles (like lamp posts). It is designed for quick, secure installation.
3. What is the name of the software to create a 3D video?
AE, MAYA, 3D Maker, 3D Max are the professional software to create a 3D video.
4. How does the led hologram display work in daylight? Is it bright enough in a sunny room?
Yes, the led hologram display is bright enough, so that it can work in a sunny room in daylight.
5. What is your return policy?
If any problems happen within 1 year you can return the hologram fan to us, we will repair it for free.
6. Does it come with a wall mount?
Yes, it comes with a wall mount bracket, the floor standing bracket is optional.
7. Is there a way to combine 2 fans to get a larger image?
Yes, it can be synchronized by 2 fans, 3 fans, 4 fans… many fans to combine to a larger and larger image.
Main Features:
Innovative 3D hologram fan solution. Patented tool-free quick installation design;
Ultra-high definition with a pixel pitch of only P1.0;
Excellent outdoor display effect,High brightness up to 2600 nit, eye visible under sunshine;
Wireless splicing synchronization over 100 square meter ;
High end and slim design, PC + Aluminum Alloy material;
Amazing 3D display effect, “WOW” effect is guaranteed;
Ultra high resolution, up to 4K; Support real-time screen projection;
Offline timer switch and timed playback;
User friendly software, APP control, support Android and iOS;
Supports cloud management software for remote central control;
Support Bluetooth audio connection.
Your Hologram Projector Frequently Asked Questions (FAQs)
What software do I need to create videos for the 3D hologram fan?
Professional software like AE, MAYA, 3D Maker, and 3D Max can be used. We also offer a free service for creating simple 3D videos.
How difficult is it to set up the holographic fan?
Most users can complete the setup within 15-20 minutes.
The tool-free design and clear instructions make installation straightforward, even for first-time users.
What is the best holographic fan for a brightly lit room?
Yes, with a brightness of over 2500 nits, it is bright enough to work effectively in a sunny room during the day.
How can I sync multiple holographic fans together?
Absolutely. You can synchronize multiple fans to create a larger, seamless holographic video wall.
Can the fan be used outdoors in heavy rain?
Yes, the IP65 rating ensures protection against heavy rain and dust. However,
we recommend avoiding direct exposure to extreme weather conditions for extended periods.
What content formats are supported?
The fan supports most common video formats including MP4, AVI, MKV, and GIF.
How long does the fan typically last?
With a rated lifespan of 50,000 hours, the fan can operate continuously for over 5 years with proper maintenance.
Can multiple fans be synchronized?
Yes, our cloud management system allows seamless synchronization of multiple fans for large-scale installations and video walls.
Software Specification:
Support cloud control, high-speed upload and download.
APP control, both Android and iOS.
Bluetooth audio connect.
Splicing function, combine multiple fans to become a video wall display.
Support format such as MP4,AVI,RMVB,JPG.
Provide Windows 10 based control software.
Rich 3D videos resource available.
Support APP turn on/off fan.
Support simple 3D words video editing.
Schedule turn on/off fan by software.
